Pipe, Tube, Angle, Channel & Flat Bar Rolling Machines


American Machine Tools Company is accedited by the Better Business Bureau! Click to verify. We accept credit cards for up to $10,000.

Large radius rolling of pipe, tube, angle, channel, flat bar, and T-shapes is usually done on a pyramid style 3 roll bender. When rolling pipe or tube, you will need the 3 rolls to match the contour of the tube to prevent the wall stress from flattening the tube. Onme die set can roll parts to different radii.

But if you want to roll your pipe/tube to a small radius that can be repeatably and accurately done, then you want a rotary mandrel draw bender machine. It uses a die set that matches the tube/pipe size and the desired exact radius. The outer die pulls the pipe (or tube) as it rotates around the inner mandrel.

The blue colored pyramid roll bender machines for rolling pieces with a large radius come with a combination set of segmented rolls that can be used in different configurations to fit the shapes you are working with. Optional rolls may be needed to productively roll some shapes and all round shapes on the pyramid roll benders. When rolling angle iron, it helps to use optional lateral angle guide rolls (expensive) to prevent twisting or you can try rolling 2 angles together that have been tack welded into a T-shape to compensate for possible twisting. Separate the 2 rolled angles when finished. But this method reduces the angle size capacity.

The yellow Baileigh rotary draw bender machines are made in USA. The blue Baileigh roll bender machines are made in Portugal. The blue GMC machines are made in Taiwan (not China).

Round Pipe and Round Tubing are not the same thing. Pipe is listed by the nominal (approximate) inside diameter but tubing is listed by the exact outer diameter. For some pipe bender machines you can also buy or make die sets to bend Square Tubing, Angle Iron, etc.
Outer Diameter of schedule 40 Pipe for Reference:
1/4 inch pipe = 0.540 inch outer diameter
3/8" pipe = 0.675" outer diameter
1/2" pipe = 0.840 outer diameter
3/4" pipe = 1.050 outer diameter
1" pipe = 1.315 outer diameter
1-1/4" pipe = 1.660 outer diameter
1-1/2" pipe = 1.900 outer diameter
2" pipe = 2.375 outer diameter
2-1/2" pipe = 2.875 outer diameter
3" pipe = 3.500 outer diameter
4" pipe = 4.500 outer diameter
5" pipe = 5.563 outer diameter
6" pipe = 6.625 outer diameter

GMC Roll Bender Machines for large radius rolling of flat bar, angle, channel, square tubing, etc.
2 Bottom Rolls are Driven // Rolls are Hardened // Cast Iron Frame // Includes a Set of Standard Rolls // Adjustable Side Guide Rolls // Overload Protection // Safety foot pedal control // Use Horizontally or Vertically.
Options available: * Rolls for round shapes. * Nylon rolls to prevent from marking up your parts.

GMC Pyramid Roll Bender Machine model PRB-30HV

Model: PRB-30HV: $3850.
Diameter of rollers: 1.12"
Rolling speed: 9 rpm
Motor: 2 HP, 110 Volts
Dimensions: 47 x 30 x 48"
Weight: 620 Lbs
Click to request more info

Image of Flat Bar Bending Machine

Model: PRB-55: $5850.
Diameter of rollers: 2"
Roller speed: 13 rpm
Motor: 3 HP, 220 Volts,1 phase
Dimensions: 40 x 35 x 65"
Weight: 1050 Lbs
Optional hydraulic top roll & DRO
Click to request this info

Picture of GMC Pipe and Tube Roll Bender Machine model PRB-65

Model: PRB-65: $12850.
with push button hydraulic powered top roll positioning and digital readout.
Diameter of rollers: 2.5"
Roller speed: 10 rpm
Motor: 3 HP, 220 Volts,3 phase
Dimensions: 50 x 45 x 71 inches
Weight: 2110 Lbs.
Click to request more info

BAILEIGH Roll Bender Machines for large radius rolling of Pipe, Tube, Angle, Channel, flat bar, etc.
• Ratcheting top roll adjustment
• Cast frame .
• Shafts are hardened steel
• Rolls are hardened and ground steel.
• Hardened Rolls for standard flat profiles included.
• Rolls for round shapes are optional.
• Made in Europe (not Turkey).
• Bottom 2 rolls are powered by electric motor controlled by forward & reverse foot pedals.
Excellent for large radius bending.

Baileigh RM55 Roll Bending Machine for pipe, tubing, angle, flat bar, etc
Click to request
this Quote

Pyramid Rolls
RM40
(just the top half of this machine tilts for horizontal use)
RM55
(push button hydraulic adjustment with digital readout is optional)
Description: Foot pedal turns 2 lower rolls forward and reverse. Manual vertical adjustment of top roll. Use horizontal or vertical. Foot pedal turns 2 lower rolls forward and reverse. Manual vertical adjustment of top roll. Use horizontal or vertical. Also available with push button hydraulic top roll position.
Shaft Diameter 1.25" 1.968"
Upper Roll Diameter 5.83" 5.83"
Lower Roll Diameters 4.64" 5.83"
Shaft Speed variable 10 to 21 rpm variable speed 13 to 27 rpm
CAPABILITIES Made in Europe Made in Europe
Flat Bar Hard Way 2.0" x 3/8" @ 8" Radius Min. 2-1/4" x 3/8" @ 16" Radius Min
2" x 1/2" @ 16" Radius Min.
Flat Bar Easy Way 2" x 3/8" @ 10" Radius Min 4" x 1/2" @ 15" Radius Min.
Solid Round 1.75" @ 10" Radius Min. 1.25" @ 24" Radius Min.
Solid Square 1.25" @ 10" Radius Min. 1.25" @ 24" Radius Min.
Angle Iron Leg In 1.5" x 1.5"x 3/16" @ 10" Radius Min./ 1 x 1 x 3/16 2" x 2" x 1/4" @ 24" Radius Min.
Angle Iron Leg Out 1.5" x 1.5" x 3/16" @ 10" Radius Min. 2" x 2" x 1/4" @ 24" Radius Min.
Tubing Round 2" x 14 ga. @ 20" Radius Min. 2.25" x .078" @ 24" Radius Min
Tubing Square 1.5" x 1.5" x 14 ga @ 20" Radius Min 1.75" x 1.75" x .078" @ 24" Radius Min.
Schedule 40 Pipe 1" @ 14" Radius Min 1-1/2" @ 20" Radius Min.
Channel 2" 2"
Electrics 220 volts, 1 phase 220 volts, 1 phase
Weight 560 Lbs 925 Lbs
BAILEIGH Roll Benders for large radius rolling of Pipe, Tube, Angle, Channel, flat bar, etc.:
All 3 rolls are powered by forward/reverse foot pedals
• Push button up-down positioning of top roll with Digital ReadOut
Steel-Welded Construction
Hardened alloy steel shafts
Top Roll Moved Hydraulically via push buttons
Machine works horizontally or vertically
Standard flat rolls included
Guide Rollers
Mobile Control Console
Brake motor equipped
• Made in Europe (not Turkey)
Optional Accessories:
Rolls for Pipe/Tube/Profiles/ High volume Angle Bending
Special Lateral Angle Guides
Pyramid Rolls
RH45
RH55
Shaft Diameter 1.77" 2.165"
Roll Diameters 6.37" 6.69"
Shaft Speed 12 rpm 11 rpm
CAPABILITIES
Flat Bar Hard Way 3 x 3/8" @ 14" Radius Min 4 x 3/8" @ 16" Radius Min
Flat Bar Easy Way 4" x 3/4" @ 14" Radius Min. 4.75" x 3/4" @ 16" Radius Min.
Angle Iron Leg Out 2 x 2 x 1/4" @ 14" Radius Min 3" x 3" x 3/16" @ 16" Radius Min.
Angle Iron Leg In 2" x 2" x 1/4" @ 14" Radius Min 3" x 3" x 3/16" @ 16" Radius Min.
Tubing - Round 2-3/4" x 14 ga. @ 30" Radius 3" x 16 ga. @ 32" Radius Min.
Tubing - Square 2" x 3/32 @ 26" Radius Min. 2-3/8" x 1/8 @ 51" Radius Min.
Schedule 40 Pipe 2" @ 24" Radius Min. 2.5" @ 29" Radius Min.
Channel 4" @ 16" Radius Min 4-1/2" @ 17" Radius Min
Electrics 220 volts, 1 phase, 3 HP 220 volts, 3 phase, 5.25 HP
Weight 1200 Lbs 1630 Lbs.
Machine size (l x w x h) 48" x 31" x 57" 51" x 35" x 62"

For frequent users, the hydraulic RH45, RH55 and RH85 machines adjust the bending radius via push buttons and they have a digital readout showing the up-down position of the bending roll to help repeat your work. On the RH85, RH120 and RH150, both bottom rolls move up and down instead of the top roll, so there are 2 digital readouts. To prevent slippage, all 3 rolls are driven on the RH45 thru RH150.

BAILEIGH RH85 PYRAMID ROLL BENDING MACHINE for large radius rolling of Pipe, Tube, Angle, Channel, flat bar, etc:
• All 3 Rolls are Powered
• Steel Frame Construction
• Standard Combo Rolls for flat shapes included
• Alloy steel Rolls & Shafts
• Rolls are Hardened and Ground
• Horizontal or Vertical Working Positions
• Brake Motor equipped
• Mobile Control Panel
• 3-Axis Mechanical Lateral Angle Guide Rolls
• Digital Read-Outs showing up-down movement of both lower rolls
Options: Pipe, Tube and Profile Bending Rolls
Capacities:
Mild Steel Max. Size OD/Wall Min. Dia.
Flat Bar (Hard Way): 3 x 1/2" @ 27.55 radius
Flat Bar (Easy Way): 5 x 1 @ 23.62 radius
Solid Square Rod: 1 3/4" @ 19.68 radius
Solid Round Rod: 2 @ 19.68 radius
Round Tube: 4 x .09 wall @ 47.24 radius
Pipe: 3 Sched 10 @ 27.55 radius
Rect Tube: 3 x 1 x 1/8 wall @ 31.49 radius
Square Tube: 2 3/4 x 1/8 wall @ 51.18 radius
Angle Iron (Leg Out): 3 x 3 x 5/16 @31.49 radius
Angle Iron (Leg In): 2 3/4 x 2 3/4 x 1/8 @27.55
T-Bar (Leg Out): 2 3/4 x 5/16 @ 31.9 radius
T-Bar (Leg In): 3 x 5/16 @ 31.49 radius
Channel (Legs Out): 4 3/4 x 2 @ 23.62 radius
Channel (Legs In): 4 x 2 @ 19.68 radius
I Beam (Hard Way): 4 3/4 x 2 1/4 @ 23.62 rad.

SPECIFICATIONS:
Shaft Diameters: 2.75"
Roll Diameters: 9.64"
Shaft Speeds: 8 rpm
Hardened Rolls for standard profiles included
Hydraulic adjustment of bottom rolls up or down - independently

Electronics: 4 HP, 220 Volts,3 phase, 60Hz
Weight: 3,300 lbs.
Dimensions (l x w x h): 56" x 38" x 52"

BAILEIGH RH120 PYRAMID ROLL BENDING MACHINE for large radius rolling of Pipe, Tube, Angle, Channel, flat bar, etc:
Click to request this Quote
• All 3 Rolls are Power driven
• Steel Frame Construction
• Standard Combo Rolls for flat shapes included
• Alloy steel Rolls and Shafts hardened & ground
• Horizontal or Vertical Working Positions
• Brake Motor equipped
• Mobile Control Panel
• 3-Axis Mechanical Lateral Angle Guide Rolls
• Digital Read-Outs show up-down movement of both lower rolls!
Options: Pipe, Tube and Profile Bending Rolls
Capacities:
Pipe: 4.5" schedule 40 @ 73" diameter
Round tube: 5.5" x .120" thick wall @ 118" diameter
Square tube: 4" x .196" thick wall@ 118" diameter
Angle iron: 4 x 4" x 3/8" @ 63" diameter
Solid square: 2.375" @ 40" diameter
Solid round: 2.75" @ 32" diameter
Flat bar - Easy way: 7.87" x 1.37" thick @ 40" dia.
Flat bar - Hard way: 4" x 1" @ 63" diameter

Photo of Baileigh RH120 Double Pinch Type Hydraulic Powered Roll Bending Machine
RH-120
Roll adjustment is push button hydraulic
Shaft diameter: 3.937"
Roll diameters Upper & Lower: 12.40"
Speeds: (2) 5 rpm, 4 rpm
Motor: 15 HP, 220 volts, 3 phase
Shipping dimensions (L/W/H): 63" / 58" / 71" Shipping weight: 4,975 Lbs

BAILEIGH RH150 PYRAMID ROLL BENDING MACHINE - Our biggest for large radius rolling of Pipe, Tube, Angle, Channel, flat bar, etc:
Click to request this Quote
• All 3 Rolls are Power driven
• Steel Frame Construction
• Standard Combo Rolls for flat shapes included
• Alloy steel Rolls and Shafts hardened & ground
• Horizontal or Vertical Working Positions
• Brake Motor equipped
• Mobile Control Panel
• 3-Axis Mechanical Lateral Angle Guide Rolls
• Digital Read-Outs show up-down movement of both lower rolls!
Options: Pipe, Tube and Profile Bending Rolls
Capacities
Pipe: 5.5" schedule 40 @ 73" diameter
Round tube: 6.25" x .120" thick wall @ 118" dia.
Square tube: 4" x .196" thick wall@ 118" diameter
Angle iron: 4-1/2 x 4-1/2" x 1/2" @ 60" diameter
Solid square: 3" @ 32" diameter
Solid round: 3.38" @ 36" diameter
Flat bar - Easy way: 7.87" x 2" thick @ 40" dia.
Flat bar - Hard way: 5.5" x 1" @ 118" diameter
Image of Baileigh RH150 Double Pinch Type Hydraulic Powered Rolling Machine
RH-150
Roll adjustment is push button hydraulic
Shaft diameter: 4.724"
Roll diameters Upper & Lower: 15.354"
Speeds: 3.25 rpm
Motor: 20 HP, 220 volts, 3 phase
Shipping dimensions (L/W/H): 79" / 59" / 80" Shipping weight: 10,400 Lbs

Small Radius Pipe & Tube Bending:
Rotary Draw Benders have the advantage of being able to form a smaller radius than 3 roll pyramid type machines (show at the top of this webpage). Though both types of machines require different dies each size of pipe or tube, draw type machines require a different die set for each radius you are trying to form. 3 roll pyramid type machines can form many different radii as long as each radius is large but require more skill to repeat the same radius, which is why rotary draw type madrel style machines are great if you have to form multiple parts of the same radius.

Die sets are interchangeable on all RMD benders. All die sets are color coded for easy identification (green for pipe, blue for tube, and gray for square). Bend Material: Round or square tubing, pipe, flat stock, angle iron, or solid rod. Custom dies available Fast change over of dies without tools. Note that the dies for these machines are selected to fit the tube or pipe size AND the size of the desired Center Line Radius.

Angle Finder Bend Degree Indicator: Indicator accurately detects where plane of bend is within the 360 degree rotation. Fits from 1" OD to 3" OD. $199. with any machine purchase

EDWARDS 10 Ton Pipe/Tube Bender : $3475.
Click to Request our quote for this machine
Made in USA. Call 773-334-5000 to order this machine.
* Operates Horizontal or Vertically
* 180 Degree Bend Capacity
* Easy To Use Hand Controls
* Auto Stop Feature For Repeatable Bends
* Heavy Duty Rolling and Locking Stand
* Quick Disconnect Hoses
* Heavy Duly All Steel Construction
* 2" (10) Schedule 40 Pipe Capacity
* 2-1/2" (00) .095" Tube Capacity
* 2-1/4" .083" Chromoly Capacity
* Pipe Die Sets Sold Separately - click to see the list
* Stroke: 14"
Electric Motor Std: 5 HP, 3 Phase, 20B/240Volts, 14 amp Electric Motor Options: 440/480 V, 575V, 3 phase, 7 amp; or 1 Phase, 220 Volts, 26 amps
Hydraulic Pump: 3-1/2 gpm-single stage@3000 psi max.

Edwards+Pipe-Tube+Bender
Head can pivot for horizontal use.
Click to see the huge list of Die Sets available

RDB-100 Manual Ratcheting Tube and Pipe Bender: $1995.

Call 773-334-5000 to order this machine. Mon - Fri 9 - 5

Capacity is up to 1" schedule 40 Pipe, 1" square tubing,
1-1/2" Chromolly (up to .083 wall), up to 1-3/4" tube (.095 wall mild steel).
Unique ratcheting mechanism allows you to bend easily by simply pulling a lever. Each pull will deliver 10 degrees of movement. No Pins to move or re-engaging to reach 206 degrees; this is accomplished by the anti-reverse stop latch. Bends pull out in seconds (no disassemble required). Maximum bend radius is 7" (depending on wall thickness, and material). Quick release counter die improves production time. Highly visible degree dial improves accuracy. Weight: 250 Lbs. Made in USA.

Image of manual ratcheting pipe bender

RDB-125 Hydraulic Rotary Draw Bender: made in USA
Click to Request our quote for this machine
Our lowest price powered pipe and tube bending machine.
Capacities:
Mild Steel or Aluminum schedule 40 Pipe: 2"
Stainless Steel schedule 40 Pipe: 1.5"
Mild Steel Round Tube: 2.5" x .125 wall
Aluminum Round Tube: 2.5" x .156 wall
Stainless Steel Round Tube: 2.25" x .125 wall
Chromolly Round Tube: 2" x .125 wall
Mild Steel Solid Rod: 1.25"
Mild Steel Square Tube: 2" x .125
Minimum OD: .25"
Maximum Center Line Radius: 7"
Minimum CLR .5"
Electrics: 110 Volts
Weight: 325 Lbs.

RDB-125 Hydraulic powered pipe and tube bending machine

RDB-150 Hydraulic Rotary Draw Bender: made in USA
Click to Request our quote for these machines
Capacities:
Mild Steel or Aluminum schedule 40 Pipe: 2"
Stainless Steel schedule 40 Pipe: 1.5"
Mild Steel Round Tube: 2.5" x .125 wall
Aluminum Round Tube: 2.5" x .156 wall
Stainless Steel Round Tube: 2.375" x .125 wall
Chromolly Round Tube: 2" x .125 wall
Mild Steel Solid Rod: 1.25"
Mild Steel Square Tube: 2" x .125
Minimum OD: .25"
Maximum Speed to 180 Degrees: 10 seconds
Maximum Center Line Radius: 7"
Minimum CLR .5"
Electrics: 120 Volts, 1 phase
Weight: 600 Lbs.

Optional: Angle-Autostop.
Extra Heavy Duty model RDB-175:
Same as model 150 but includes faster pump, foot pedal, angle-autostop, and larger maximum bend radius of 9".

RMD model 150-S hydraulic tube and pipe bending machine
RDB-250 Electric Programmable Bending Machine:
Click to Request our quote for this machine
Mild Steel schedule 40 Pipe: 2.5"
Aluminum schedule 40 Pipe: 3"
Stainless Steel schedule 40 Pipe: 2"
Mild Steel Round Tube: 3" x.187 wall
Aluminum Round Tube: 3.5" x.250 wall
Stainless Steel Round Tube: 3" x .125 wall
Chromolly Round Tube: 2.5" x .125
Mild Steel Solid Rod: 1.5"
Mild Steel Square Tube: 3" x .125
Maximum Center Line Radius: 9", Min CLR: .5"
Electrics: 220 volts, 1 phase
Weight: 620 Lbs.

Optional: Programmable Memory

Made in USA
RDB-250 Programmable Electric Pipe and Tube Bending Machine

RDB-350-TS Electric Programmable Bender:
Click to Request our quote for this machine
This tubing bender has a maximum CLR is 24" which is our largest for these machines, Touch Screen Programming with memory for 175 programs.
Mild Steel schedule 40 Pipe: 2.5"
Aluminum schedule 40 Pipe: 3"
Stainless Steel schedule 40 Pipe: 2"
Mild Steel Round Tube: 3" x.187 wall
Aluminum Round Tube: 3.5" x.250 wall
Stainless Steel Round Tube: 3" x .125 wall
Chromolly Round Tube: 2.5" x .125
Mild Steel Solid Rod: 1.5"
Mild Steel Square Tube: 3" x .125
Maximum Center Line Radius: 24"
Minimum CLR: .5"
Electrics: 240 volts, 3 phase.
Weight: 1200 Lbs.
made in USA.

RDB-350TS Programmable Electric Pipe and Tube Bending Machine
Made in USA

RDB- 500 Hydraulic Rotary Draw Bender:
Click to Request our quote for this machine
Mild Steel schedule 40 Pipe: 3"
Aluminum schedule 40 Pipe: 3.5"
Stainless Steel schedule 40 Pipe: 2.5"
Mild Steel Round Tube: 3" x .250 wall
Aluminum Round Tube: 3.5" x .187 wall Stainless Steel Round Tube: 3.5" x .187 wall
Chromolly Round Tube: 3.5" x .187 wall
Mild Steel Solid Rod: 2"
Mild Steel Square Tube: 3" x .250 wall
Maximum Speed to 180 Degrees 36 Seconds
Maximum Center Line Radius: 12", Minimum CLR .5"
Electrics: 220 volts, 1 phase, 30 amps.
Weight: 1800 Lbs.

One shot bending up to 206 degrees without stopping or ratcheting. Bends pull out in seconds (no disassembly required). Unique design coupled with powerful hydraulic pump reduces production time and improves efficiencies. Quick release counter die. Highly visible degree dial improves accuracy. Solid steel construction for durability. High quality industrial hydraulic system. Bend can be advanced after stopping machine, saves on set up costs (material savings). Bend round or square tubing, pipe, flat stock, angle iron, or solid rod. Autostop option for one bend programming. Made in USA.

RDB-500 Hydraulic powered pipe and tube bending machine

Made in USA


HPB-45

45 Ton Hydraulic Horizontal Press
Click to Request our quote for this machine
Stroke in and stroke back is controlled with two hand wheel adjustments and also in a digital version that allows for programming several hundred complex functions. Table is made with tempered and ground steel, the carriage runs on double guides with dust scraper and forced lubrication. The mobile pin moves at two speeds and the stroke is adjusted via a high precision electrical limit switch. Built in lubrication system. Standard 90° bending die set included for flat bar (bends rebar too).

Max operating pressure: 45 Tons
Table Dimensions: 630 x 1100 mm
Table height: 955mm
Press bending capacity: 120 x 15mm
Stroke adjustment: 250mm
Tool Holding Pins Height: 120mm
Tool Holding Pins Diameter: 55mm
Distance between pins:120mm Min/370mm Max
Motor: 4 HP, 240V, 3 Phase, 60 Hz.
Horizontal Bending press dimensions:
1200mm wide x 1150mm long x 1110mm high
Weight: 900 kg

Click for our Machinery Safety webpage

Click for our Pipe and Tube Notching machines webpage

Click for American Machine Tools Company Homepage

Privacy Clause

American Machine Tools Corp.
5864 Northwest Hwy
Chicago IL 60631 USA

Phone: 773-334-5000
Fax: 773-442-0314

Click to email us

Terms & Conditions

Frequently Asked Questions

Website by eMarketAmerica
Copyright
American Machine Tools Corp

All rights reserved
Information in this website is subject to change without notice.
Offers from American Machine Tools Corporation include include Terms and Conditions shown on our website.
Liability is strictly limited to those warranties of fitness for purpose and safety as provided by the manufacturer.
Products and Logos in this website are trademarks or registered trademarks of their respective companies or mark holders.
