Hydraulic Ironworker Machines:

For punching holes of many sizes and shapes. For cutting, shearing, notching and bending metal flat bar and angle iron. We also offer custom punching, notching and forming dies. Faster than a drill press, saw, torch, or press brake for most tasks. Our most versatile machine.

35-ton Porta-Punch with hydraulic pump $3250.
• Operates from a 1/2 HP, 115 volt electric hydraulic pump - included.
• Comes in metal carrying case.
• Can punch round, oblong, square, hex and rectangular holes.
• Can be mounted to a workbench for production jobs.
• 3/8" female coupler attached.
• Punching Capacity: 13/16" round hole through 1/2" thick mild steel maximum.
• Throat depth: 2.75" • Weight: only 32 Lbs.
Price: $3250. with hydraulic pump and 4 round punches up to 13/16 diameter
DEMO MODEL available for $2795.

50-ton McPunch with hydraulic pump $5995.

Max. Round Capacity 1" dia. in 5/8" plate
Max. Square Capacity 3/4" dia. in 5/8" plate
Throat Depth: 4-1/4"
Cycle Time: 3 seconds
Stroke: 1-3/8"
Weight: 225 lbs.
Dimensions: 12" x 5-3/4" x 18-3/8"
5 HP, 3 Phase, 208/240Volts, optional 220V, 1phase 440V,3phase
TOOLING OPTIONS & ACCESSORIES:
Punch and Die Starter Box, Round Punches, Slot Punches, Metric Round Punches, Hex Punches, Laser Light Alignment Tool, 20'-40' Hose Kits, Oblong Punches, Suspension Spring.

50 Ton moveable beam punch normally supported by hoist or crane

Edwards Hydraulic Ironworkers These compact, well designed, well built, uncomplicated iron workers offer the biggest tonnage per dollar for your fabrication shop. They work on the same principal with the center pulling straight down on the work. All tooling moves vertically, with no arc of a pivot arm. Most models come standard with a punching station, flat bar shear, angle iron shear, and sometimes a coper-notcher. They operate so you can move from punch to plate shear to angle shear to notcher without always changing equipment. Many different sizes and styles of punch & die sets are available such as round, oblong slot, square, rectangle, keyhole, etc. Many kinds of optional tooling available (coper-notcher, press brake, pipe notcher, angle notcher, rod shear, gaging table, back gauge, and even radius notching). Scoll down to see. These machines are shipped ready to operate with hydraulic oil, and blades. All you have to do is connect the electricity. Optional 220 volts, single phase electrics available for most machines at $200 extra. 440/480 volts costs $100 extra. Currently all 50 Ton and larger machines include electronic stroke control and a tool box of 8 round punch sets. Made in USA.
Edwards 25 Ton "Jaws Junior"(shown on right side) Punch 1" diameter thru 5/16" thick plate. Shear 1/4 x 6" (with optional Multishear). Cut 2 x 2 x 1/4 angle (with optional Multishear). Electrics: 220 volts,1 phase, or 110 volts. Light duty starter machine that has 2 hydraulic powered stations to fit almost any 2 sets of tooling. Comes with a punching head on left side, but the flat bar shear and angle shear are in an optional attachment that mounts on the right side instead of being built into the machine as is on our larger sizes. Mfr's List Price: $4295. Our price is $3895. Click to Request this Quote and info packet Made in USA.
40 Ton "Jaws 4" Ironworker machine Made in USA. Has Flat Bar Shear, Angle Shear, removable Punching Head, and it has a hydraulic powered right side for any optional tooling. 7" throat, 8" open height, 1" stroke Punches 1" diameter thru 1/2" thick steel plate Plate Shear cuts 3/8 x 10" steel plate Angle Shear cuts 3 x 3 x 1/4" angle iron. Optional Tooling Available: Coper-Notcher, Pipe Notcher, Press Brake, Extra large Punching Assembly, Angle Vee Notcher, Rod Shear, Gauging Table, Back Gauge, Urethane Stripper. Weight: 1200 pounds. Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase Scroll down to see optional tooling below. Mfr's List Price: $5895. includes tool box of 8 punch & die sets. Optional 2" capacity pipe bender attachment: $1995. extra Click to Request Our Lowest Price and info packet	Photo shows optional 45° & 90° pipe notchers on lazy-susan tray in hydraulic powered right side.
50 Ton "Jaws 4" Iron worker machine Made in USA. (alot lighter than the 55 ton machine) Has Flat Bar Shear, Angle Shear, removable Punching Head, and on the right side the Coper-Notcher-Nibbler is optional. 7" throat, 8-1/8 open height, 1-1/8 stroke Punches 1" diameter thru 5/8" thick steel plate or 1-9/16 dia thru 3/8 with oversize punch option. Plate Shear cuts 1/2 x 10" or 3/4 x 4", 1" rod Angle Shear cuts 4 x 4 x 1/4" angle or 3 x 3 x 3/8" angle. Optional Coper-Notcher 2 x 3 x 5/16" (The only option that fits on the right side) Weight: 1400 pounds. (please compare to 55 ton) Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase Scroll down to see optional tooling below. Mfr's List Price: $6895. includes tool box of 8 punch & die sets Click to Request Our Lowest Price and info packet
Edwards 55 Ton"Jaws 4" Ironworker Made in USA. (heavier and more versatile than the 50 ton machine) Has Flat Bar Shear, Angle Shear, removable Punching Head, and on the right side any optional extra tooling can fit there. 2 versatile power stations can use any 2 sets of tooling including 2 punch heads. Scroll down to see tooling below. 7 " throat, 8-1/8 open height, 1-1/4 stroke Punch 1-1/16" diameter thru 5/8" thick steel plate or 1-3/8 dia thru 1/2 with oversize punch option. Built in Bar Shear cuts 1/2 x 12", 3/8 x 14", 3/4 x 4", 1-1/8 round Built in Angle Shear cuts 4 x 4 x 1/4" angle or 3 x 3 x 3/8" angle or smaller. Coper-Notcher 2 x 4 x 5/16" (option shown in photo) Weight: 2250 pounds. Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase. The 55 ton is Edwards' most popular machine because it is heavy, low priced, can hold any two sets of tooling such as a punching head and pipe notcher or press brake and coper-notcher or 2 punching heads and is usually in stock. Mfr's List Price: $7295. includes tool box of 8 punch & die sets. Click to Request Our Lowest Price and info packet * One of our recent customers would like to sell his 55 Ton 220volts,1phase due to a medical problem: Call him; Tom Gardner 785-449-2138 Kansas *	Photo shows optional notcher in hydraulic powered right side.
Edwards 60 Ton "Jaws 4" Iron worker Made in USA. (very similar to 55 ton but stronger with built in coper-notcher on right side) 7-1/2" throat, 8-1/4 open height, 1-1/4 stroke Punch 1-1/16" diameter thru 3/4" thick steel plate or 1-1/2 dia thru 1/2 with oversize punch option. Built in Bar Shear cuts 1/2 x 12", 3/8 x 14", 3/4 x 4", 1-1/8" round Built in larger angle shear cuts 4 x 4 x 3/8" or 3 x 3 x 1/2" angle or smaller. Built-in Coper-Notcher 2-1/2" x 5" x 1/4 or 2-1/2" x 4" x 3/8" Scroll down to see optional tooling below. Weight: 2500 pounds. Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase. Mfr's List Price: $8495. includes tool box of 8 punch & die sets Click to Request Our Lowest Price and info packet
Edwards 65 Ton "Jaws 5" Iron worker Made in USA. 10" throat, 8-1/8 open height, 1-3/8 stroke Punches 1-1/16 diameter thru 3/4 thick steel plate or 1-9/16 dia thru 1/2 with oversize punch option. Built in Plate Shear cuts 3/8 x 24", 1/2 x 14", 1" x 4", 1-1/4 round Built in Angle Shear cuts 5 x 5 x 1/4 angle or 4 x 4x 3/8 angle. Built-in Coper-Notcher (2-1/2 x 6 x 3/8) included Spare hydraulic cavity to power extra set of tooling. Scroll down to see optional tooling below. Weight: 3550 pounds. Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase Mfr's List Price: $13,395. includes tool box of 8 punch & die sets Click to Request Our Lowest Price and info packet	Photo shows tooling option in spare hydraulic powered cavity.
Edwards 75 Ton "Jaws 4 " Iron worker Made in USA. 10" throat, 8-3/4 open height, 1-5/8 stroke Punches up to 1-1/16" diameter thru 7/8 thick steel plate or punch 1-1/2 dia thru 5/8 thick plate with oversize punch option. Built in Plate Shear cuts 1/2 x 14, 3/4 x 10", 1-1/4 round bar Built in Angle Shear cuts 5 x 5 x 3/8 angle Coper-Notcher 2-1/2 x 5 x 1/2 (tooling option for right side) Weight: 3150 pounds. Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase Scroll down to see optional tooling below. Mfr's List Price: $12,295. includes tool box of 8 punch & die sets Click to Request Our Lowest Price and info packet
Edwards 100 Ton "Jaws 4" Ironworker Made in USA. 10" throat, 8-5/8 open height, 1-5/8 stroke Punch 1-1/16" diameter thru 1" thick steel plate or 1-9/16 dia thru 3/4 with oversize punch option. Built in Flat Bar Shear cuts 3/4 x 14, 1" x 10", 1-1/4 round Built in Angle Shear cuts 6 x 6 x 1/2 angle Coper-Notcher 2-1/2 x 6 x 1/2 (optional) 2 versatile cavities power any 2 sets of tooling including 2 punch & dies. Weight: 3700 pounds. Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase Scroll down to see optional tooling below. This 100 ton is a popular machine because it is heavy, low priced, and can hold any two sets of tooling such as a punching head and pipe notcher or press brake and coper-notcher or 2 punching heads. Mfr's List Price: $14,995. includes tool box of 8 punch & die sets Click to Request Our Lowest Price and info packet	Photo shows press brake option in hydraulic powered right side.
Edwards 100 Ton "Jaws 5" Deluxe Iron worker Faster Production Ironworker. Made in USA. 10" throat, 8-1/2 open height, 1-1/2 stroke. Punch 1-1/16" diameter thru 1" thick steel plate or 1-9/16 thru 5/8 with oversize punch option. Built in Shear cuts 1/2 x 16", 3/4 x 12, 1" x 7, 1-1/2 round. Built in Angle Shear cuts 5 x 5 x 1/2 angle. Built in Coper-Notcher (3 x 6 x 3/8) included. Built in Rod Shear for round and square. Weight: 4700 pounds. Electrics: 220 Volts, 3 phase. Optional 440V. 220V, 1 phase is special. Mfr's List Price: $18,795. includes tool box of 8 punch & die sets Click to Request Our Lowest Price and info packet
Edwards 120 Ton & 150 Ton Heavy Duty Machines 11" throat, 9-1/8 open height, 1-1/8 stroke Punch 1-1/16 diameter thru 1" plate (1-1/2 dia with oversize punch option) Built in Shear cuts 1/2" x 24", 1" x 12", or 1-1/4 square or round Built in Angle Shear cuts 6 x 6 x 1/2 angle Built-in Coper-Notcher (3 x 6 x 1/2) included Spare hydraulic cavity to power extra set of tooling. Quick cycle time of 2.5 seconds. Weight: 5500 pounds. Electrics: 10 HP, 220 Volts, 3 phase. Optional 440V or 575V. Scroll down to see optional tooling below. All New Design! Also available in 150 Ton Made in USA. Mfr's List Price: $20,995. includes tool box of 8 punch & die sets Click to Request Our Lowest Price and info packet	Photo shows option in spare hydraulic powered cavity.

Edwards Iron worker Tooling: Made in USA. Coper-Notcher, Angle-Notcher, Pipe Notcher, Press-Brake, Rod-Shear, Custom Channel-Shear, Spare Punching Assembly, Extra Large Punching Assembly, Quick Change Punch Coupling, Magnetic Bar Fence, Gaging Table, Pedestal Die Table, Picket making and many sizes and styles of punch & die sets. The 55 ton, 65 ton, 100 ton and 120 ton machines have a powered spare tooling station to use almost any of the tooling shown or to use your own custom die set without having to unbolt the punching head. Only the 55 ton and 100 ton Jaws IV ironworkers have the option of holding 2 punching assemblies simultaneously (1 on each side). Custom tooling also available. SCROLL DOWN TO SEE TOOLING PICTURES
Coper-Notcher-Nibbler Standard on 60, 65, 100 deluxe, 120 ton. Used for square, rectangular or angle V notching. Copes angle iron flanges. CLICK FOR VIDEO	Press-Brake Has 4-way style lower die. Has V die openings for bending metal 1/16, 1/8, 3/16, and 1/4" thick. Can bend 3/8". CLICK FOR VIDEO	Pipe Notcher Cuts pipe with a semi-circular cut to allow one pipe to fit 90° against another for railings. Sizes from 1/2 to 2" pipe. CLICK FOR VIDEO
Vee-Notcher (3 x 3 V shaped notch up to 1/4 thick., but the Coper-Notcher also V notches)	Rod-Shear (shears 1/4, 3/8, 1/2, 5/8, 3/4, 1"diameter rod cleanly and quickly)	Pedestal Die Table (for punching 2"angle iron leg down. Included with most ironworkers)
Large Gauging Table (for attaching jigs, fixtures & fences. Choose from 3/8" thick or 1" thick)	Protractor Angle Gauge Sets the pice part angle when shearing flat bar or when punching.	Urethane Stripper (prevents distortion when punching soft aluminum, copper, brass, bronze, etc.)
Adjustable Back Gauge for setting repeat distances for punching holes, shearing angle and shearing flat bar.	Automatic Cut Back Gauge for setting repeat distances for punching or shearing. Automatically cuts without stepping on foot pedal.	Electric Stroke Control Saves time by shortening stroke when punching thin metal or to control upper press brake die for repeat bend angles.
Stripper Reducer minimizes distortion in thin metals when using smaller punches & dies	Oversize Punching Assembly includes oversize punch stem, nut, & die table for punching up to 1- 9/16" dia.	241 Large Punching Assembly for punching up to 4"diameter. Can also be used for corner radius notching.

H.M.I. Heavy Duty Ironworkers offer the most versatile press / punch of machines available today. The extra large throat depth, height and extra long stroke not found on most machines allows for a huge number of uses. The infinitely adjustable stroke from zero to 6", 8", or 11" depending on the model, makes it one of the most versatile machines available for using custom punching and forming dies. Press brake tooling up to 4 feet long can be used. These machines work great as an Ironworker and as a Hydraulic Press.

Models 4214 thru 15010 are dual operation with 1 foot pedal for punch and 1 hand lever for shear & notcher.
Models 7031 thru 20031 are dual operation with 1 pedal for punch press, 1 pedal for shear & notcher.

Options: Large hole punches up to 6" dia / Press Brake up to 48" long / Extra long stroke for punching and bending / Notcher for pipe, round tube, square tube, rectangular tube / Tube Slitter / Channel Shear to 8" / Rod Shear / Production Tables for repeat punching. Made in USA.

H.M.I. Ironworker / Punch Press - single operation

Photo of HMI Ironworker / Punch Press - dual operation model

H.M.I. Ironworker / Punch Press - double operation

CLICK MODEL # for quote	5807 5814	8010	10010	12010	15010	70-31	90-31	110-31	130-31	200-31
CAPACITY	58 tons	80 tons	100 tons	120 tons	150 tons	70 tons	90 tons	110 tons	130 tons	200 tons
CONTROLS	Dual Operation (1 foot pedal + 1 hand lever)					Dual Operation (2 foot pedals)
THROAT DEPTH	7" 14"	10"	10"	10"	10"	14"	14"	14"	14"	14"
THROAT HEIGHT	12" 18"	14"	14"	14"	14"	18"	18"	18"	18"	18"
HOLE CAPACITY EXAMPLE	15/16" in 3/4"	15/16" in 7/8"	1-3/16 in 1"	1-3/16 in 1-1/8"	1-5/16 in 1-1/4"	7/8" in 7/8"	1-1/16" in 1"	1-3/16 in 1-1/8"	1-1/4" in 1-1/4"	1-1/2" in 1-1/2"
MAX LARGE HOLE	6" Dia	6" Dia	6" Dia	6" Dia	6" Dia	6" Dia	6" Dia	6" Dia	6" Dia	6" Dia
MAX STROKE	6" 11"	8"	8"	8"	8"	11"	11"	11"	11"	11"
PRESS PLATEN SIZE	20.0" x 12.0" 38.0" x 16.0"	32.0" x 16.0"	32.0" x 16.0"	36.0" x 14.0"	36.0" x 14.0"	39.0" x 17.0"	39.0" x 17.0"	44.0" x 17.0"	44.0" x 17.0"	44.0" x 17.0"
SHEAR BLADE SIZE	20"	24"	24"	24"	24"	31"	31"	31"	31"	31"
MAX FLAT SHEAR SIZES	¾"x 6; ½"x 8; 3/8" x 12"; 1/8" x 19.5"	1" x 6"; 3/4" x 11"; 5/8" x 14"; 1/2" x 18"; 3/8" x 22", 1/4" x 24.5"				1" x 14"; 3/4" x 21"; 1/2"x 24"; 3/8" x 27", 1/4" x 30.5"			1" x 14"; 3/4" x 21"; 3/4" x 24"; 3/8" x 27", 1/4" x 30.5"
MAX SIZE SHEAR ROUND	1"	1-3/8"	1-3/8"	1-3/8"	1-3/8"	1-7/8"	1-7/8"	1-7/8"
COPER NOTCHER SIZE	2 x 2-3/4 x 5/16	3 x 3 x 3/8"	3 x 3 x 3/8"	3 x 3 x 3/8"	3 x 3 x 3/8"	3 x 4 x 1/2"	3 x 4 x 1/2"	3 x 4 x 1/2"	3 x 4 x 1/2"	3 x 4 x 1/2"
ANGLE SHEAR	4" x 4" x 1/4"	4" x 4" x 3/8	4" x 4" x 3/8	4" x 4" x 3/8	4" x 4" x 3/8	5" x 5" x 1/2"	5" x 5" x 1/2"	5" x 5" x 1/2"
MOTOR	3 HP	10 HP	15 HP	20 HP	20 HP	10 HP	10 HP	10 HP	10 HP	25 HP
WEIGHT in Lbs.	2,415 4,150	5,400	6,250	7,388	8,520	8,140	9,860	12,010	13,262	19,520
